SECTION 12 35 50.56
LABORATORY CASEWORK AND WORK SURFACES

SECTION INCLUDES
A. Solid Phenolic Composite Laboratory Work Surfaces.
B. Laboratory Casework and Cabinetry.

SUPPLIER

A. Basis of supply or fabrication:
Total Laboratory Solutions www.PhenolicResinLabs.com
Ph: 480.488.6421
Email: Sales@PhenolicResinLabs.com

B. Basis of Design:
Trespa Solid phenolic flat panels based on 30% thermosetting resins homogenously reinforced with 70% wood fibers and manufactured under high pressure and temperature to form a composite panel. Panels to have an integrated, decorative surface with pigmented resins cured using 'Electron Beam Curing' (EBC) technology, rendering the panel highly chemical resistant and highly antibacterial activity of > 99.99% reduction after 24 hours using testing method based on JIS Z 2801: 2000.

C. Requests for substitutions will be considered in accordance with provisions of
Section 01 60 00 - Product Requirements.

WORK SURFACES / BENCH TOPPINGS

A. General: Solid phenolic composite panel construction with black core.

1. Model: Trespa TopLab Plus - Laboratory Grade
2. Thickness: minimum 3/4" (20mm) or industry standard maximum 1" (25mm).
3. Finish: Crystal Smooth Finish
4. Exposed edge Finish: 1/8 inch bevel (3mm) or 3/16 inch (4.75mm) radius.
5. Backs and Side Splashes: Supplied loose, cut to size, field applied in the same material and color as countertops. Applied splash may be 3/4 inch (20mm)
or 1 inch (25mm) thickness. Curbs as installed shall be 4 inch high (100mm) typical, unless otherwise indicated on drawings. Backsplash and return side splash curbs will be bonded to the tops at the jobsite with two part epoxy resin adhesive. Include top mounted end curb where work surfaces abut walls, cabinets, fume hoods, and locations detailed on Drawings.
6. Maximum length without seam, up to 97 inch 2464mm) or 120 inch (3048mm).
7. Drip grooves of 1/8 inch depth, 1/8 inch wide (3mm) and set back 1/2 inch (12.5mm) on the underside at front of exposed edges.
8. Color: Chosen From Manufacturer's standard color range, to include:

Trespa TopLab Plus Colors:

  • Color: Black T90.0.0. - Industry Standard In Stock 1/2"; 5/8"; 3/4" and 1" Thick
  • Color: Slate Gray T70.0.0 In Stock 3/4" and 1" thick
  • Color: Regular White T03.0.0. In Stock 3/4" and 1" Thick
  • Color: Silver Grey T03.4.0. In Stock 3/4" and 1" Thick
  • Color: Pastel Grey T03.1.0. Limited Stock 3/4" Thick
  • Color: Mystic White T18.0.1. Extended lead time 3/4" & 1
  • Color: Polar Green T30.0.1.
  • Color: Limestone Yellow T05.0.1.
  • Color: Glacier Blue T21.1.1.
  • Color: Canyon Red T09.3.4.
  • Color: Speckled - Pastel Grey/Silver D02.1.0.
  • Color: Black Craquele / CO-09 Extended lead time

Download complete lab casework and work surface specification



CASEWORK AND CABINETRY

A. Basis of supply or fabrication:
Total Laboratory Solutions www.PhenolicResinLabs.com
Ph: 480.488.6421
Email: Sales@PhenolicResinLabs.com

B. Basis of Design:
RESISTOP Solid Phenolic produced with decorative kraft papers impregnated with Phenol Formaldehyde Resins (Phenolic Resins) with melamine resin on surface faces with a clear protective overcoat, integrally compression molded under high heat and pressure to form a composite panel.


1. Fire resistance: Core meets Underwriters Laboratories (UL) Class A fire resistance per ASTM E 84.
2. Fire resistance: Core meets Underwriters Laboratories (UL) Class B fire resistance per ASTM E 84.

COLORS


a. Core / Edge Color - Black
b. Finish: CA = Cashmere finish; MA = Matte Finish
c. Interior color: White S-550 CA-Elegant White or same color as exterior, as indicated on drawings.
d. Exterior Color: Chosen From supplier's standard color range, to include:

Solids:
S405 CA-Black; S-406 CA-Silver Grey; S-407 CA-Ivory;
S-431 CA-Willow Grey; S-434 CA-Charcoal Slate grey; S-436 CA-Sand;
S-444 CA-New Sand; S-445 CA-Almond; S-463 CA-Antique White;
S-466 CA-Bright Red; S-486 CA-Beige; S-513 CA-Denim Blue; S-517 CA-Saguenay; S-542 CA-Limousine Grey; S-548 CA-Custom Grey; S-550 CA-Elegant White; S568 CA-Midnight Blue.

Patterns:
P-203 CA-Van Gogh Charcoal; P325 CA-Brushed Pewter; P500 CA-Black Stone; P999 CA-Pewter; P623 CA-Brushed Aluminum; P885 CA-Black Grit; P886 CA-Grey Grit.

Wood Grains:
W-403 CA-Natural Anegre; W-405 CA-Cherry Brandy;
W-138 CA-Burnished Cherry: W-1531 CA-Gold Speckle Maple;
W-1538 CA-Fruity Pear; W-1539 CA-Architectural maple; W-372 CA-Mahogany; W230 CA-Sliced Red Oak; W411 CA-Copper Wood; W417 CA-Spiced Walnut; W425 CA-Burnished Rosewood.
